| Specification | NDFC930 | NDFC1100 | NDFC1200 | NDFC1300 | NDFC1400 | NDFC1500 |
|---|---|---|---|---|---|---|
| Max. Sheet Size (mm) | 880 × 670 | 1050 × 800 | 1150 × 830 | 1250 × 920 | 1350 × 1000 | 1450 × 1050 |
| Min. Sheet Size (mm) | 470 × 340 | 550 × 410 | 600 × 420 | 650 × 470 | 700 × 510 | 750 × 530 |
| Die-cut Accuracy (±mm) | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
| Speed (sheets/min) | 25 | 23 | 23 | 18 | 18 | 18 |
| Motor Power (kW) | 4 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 |
Six models from NDFC930 (max sheet 880 × 670 mm) up to NDFC1500 (max sheet 1450 × 1050 mm), covering small-format cartons through large display boxes, all with a die-cutting accuracy of ±0.75 mm.
18–25 sheets per minute depending on model — smaller formats like NDFC930 run up to 25 sheets/min, while the largest NDFC1500 runs at 18 sheets/min.
Sheets are fed automatically from the stack rather than loaded one by one by hand, which keeps cycle times consistent and reduces operator fatigue on long runs.
Motor power scales with model size, from 4 kW on the compact NDFC930 up to 7.5 kW on the largest NDFC1400 and NDFC1500 models.
Yes — on-site installation, commissioning and operator training are included with every machine, with after-sales support available.
Tell us your requirements and our engineers will send specifications and a tailored quote.
Request a Quote →
