| Specification | BMC-1300FSA3-HII | BMC-1600FSA3-HII |
|---|---|---|
| Max size | 1300mm×1200mm | 1600mm×1200mm |
| Min size | 360mm×360mm | 360mm×360mm |
| Economic speed | 0–100pcs/min | 0–100pcs/min |
| Precision | ±1mm | ±1mm |
| Power | 7.5 kW | 7.5 kW |
| Size | 9mx1.95mx1.7m | 9mx2.25mx1.7m |
| Weight | About 2 tons | About 2.5 tons |
The H-II shares the same servo semi-automatic platform but is optimized for higher gluing accuracy with an upgraded glue-dosing system and a longer lamination pressure zone, making it better suited for thicker corrugated boards and premium packaging.
BMC-1300FSA3-HII (max 1,300 × 1,200 mm) and BMC-1600FSA3-HII (max 1,600 × 1,200 mm), both with 1,000 kg face paper table capacity.
140–600 g/m², handling lightweight liners through heavy-duty printable cover stock.
A, B, C, E and F flutes up to 8 mm board thickness, covering standard single-wall corrugated grades.
Yes. Installation, commissioning and operator training are included with every machine. BMC engineers stay on-site until the line reaches target output.
