| Specification | NDSA-2800GM |
|---|---|
| Max feeding width (mm) | 2800 |
| Min feeding width (mm) | 750 |
| Max feeding length (mm) | 1300 |
| Min feeding length (mm) | 300 |
| Feeder height (mm) | 900 |
| Power (kW) | 3 |
| Weight (kg) | 2000 |
| Speed (pcs/min) | 40β60 |
| Machine size (mm) | 4300 Γ 2000 Γ 1700 |
Cartons are fed and processed one piece at a time through the main form and conveyor sections, with the operator assisting feed while the machine handles forming, gluing and delivery automatically.
Feeding width from 750β2800 mm and feeding length from 300β1300 mm, suitable for a wide range of box styles within a single machine.
40β60 pieces per minute, depending on carton size and material β well suited to small-to-medium batch runs.
Name-brand imported parts including Siemens electrics, Omron photoelectric switches, Japan TOKY counters and Taiwan MINGWEI power supplies, chosen for reliability in continuous operation.
The gluer head is made from a special alloy that resists both acid and alkaline exposure, extending service life compared to standard metal heads.
Tell us your requirements and our engineers will send specifications and a tailored quote.
Request a Quote β
