| Specification | PYQ401C | PYQ203D | ML1100 | ML1200 | ML1300 | ML1400 | ML1500 | ML1600 | ML1800 | ML2000 | ML2200 | ML2500 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Max Effective Cutting Area | 750×520mm | 930×670mm | 1100×800mm | 1200×830mm | 1300×920mm | 1400×1000mm | 1500×1050mm | 1600×1250mm | 1800×1300mm | 2000×1400mm | 2200×1450mm | 2500×1600mm |
| Working Speed | 28 ±2(strokes/min) | 23 ±2(strokes/min) | 20 ±2(strokes/min) | 20 ±2(strokes/min) | 18 ±2(strokes/min) | 18 ±2(strokes/min) | 18 ±2(strokes/min) | 16 ±2(strokes/min) | 16 ±2(strokes/min) | 16 ±2(strokes/min) | 16 ±2(strokes/min) | 13 ±2(strokes/min) |
| Creasing & Cutting Length | <15m | <25m | <32m | <35m | <35m | <45m | <45m | <52m | <62m | <80m | <90m | <92m |
| Motor Power | 2.2kW | 4.0kW | 5.5kW | 5.5kW | 5.5kW/7.5kW | 5.5kW/7.5kW | 5.5kW/7.5kW | 11kW | 15kW | 15kW | 18kW | 22kW |
| Machine Weight | 2000kg | 3000kg | 4500kg | 4800kg | 6000kg | 6500kg | 7000kg | 9000kg | 10840kg | 14500kg | 16500kg | 20000kg |
| Dimension (L×W×H) | 1260×1350×1280mm | 1800×1600×1600mm | 1900×1800×1700mm | 1900×2000×1700mm | 2000×2400×1900mm | 2000×2450×1900mm | 2000×2500×1930mm | 2170×2560×2130mm | 2240×2850×2230mm | 2280×3000×2230mm | 2280×3000×2250mm | 3580×2400×2550mm |
Twelve models from PYQ401C (750 × 520 mm cutting area) up to ML2500 (2500 × 1600 mm), covering small cartons through oversized display and pallet boxes.
13–28 strokes per minute depending on model — smaller machines like PYQ401C run faster at 28±2 strokes/min, while the largest ML2500 runs at 13±2 strokes/min due to its size.
From under 15 m on the smallest model (PYQ401C) up to under 92 m on the largest (ML2500), covering both short sample runs and long production batches.
Model selection depends mainly on your maximum sheet size and required cutting/creasing line length. BMC engineers can recommend the right model based on your typical box dimensions and output targets.
Yes — installation, commissioning and operator training are included for every model in the range, with after-sales support available.
Tell us your requirements and our engineers will send specifications and a tailored quote.
